LAR vertical cryogenic tanks

LAR vertical cryogenic tanks

are vertical double-layer vacuum-insulated storage tanks for storing liquid oxygen, nitrogen, argon, carbon dioxide, and other media.
vertical /lo2 /ln2/ lar cryogenic tanks
The primary function is to fill and hold low-temperature liquid.

LAR cryogenic tanks

Vertical stationary storage tanks are specially engineered and manufactured for optimal storage and applications of all cryogenic gases (N2, O2, Ar, CH4) and CO2 and N2O. Their high-quality vacuum-perlite insulation guarantees low evaporation rates for extended long-term storage; all components of each tank are cleaned and certified for oxygen service, and their durable coating of carbon steel outer tanks provides exceptional corrosion resistance.
DSW has long been recognized as a premier provider of LAR storage tanks and cryo equipment to transport and store liquefied gases for Industry markets, particularly Electronics, Health, and Energy Transition.

MATERIALS, VALVES, AND INSTRUMENTS Using stainless steel ensures reliability and extended equipment life, from inner vessels and pipes to valves, supports, lifting lugs, instruments, pressure build-up vaporizer, and all welded connections. Plumbing made from this material is pickled and passivated for use in either industrial environments or onshore locations – on request. An easily adjustable multifunctional regulator serves both pressure regulation and economization functions while the pressure build-up coil is made of aluminum finned tubes filled with stainless steel core tubes; the inner tank is protected against overpressure with dual safety relief valves while the outer tank is secured using safety discs – guaranteeing the longevity of service life for years!

LAR CRYO TANKS -DESIGN CODE      These tanks were constructed by PED, EU Directive 2014/68/EU, and EN13458 Code and hold Certificate TPTC 032/2013 from Russian Federation Customs Union countries for export.

LAR Cryogenic Storage Tank Specification

Cryogenic Liquid Tanks

Cryogenic Liquid Tanks



Cryogenic Liquid Tanks

LN2_LAR vertical cryogenic tank

LN2_LAR vertical cryogenic tank

LN2_LAR vertical cryogenic liquid tanks
The LAC vertical cryogenic tanks for liquid nitrogen products are most popular in India, Pakistan, Vietnam, Indonesia, Brazil, Russia, Mexico, United States, Turkey, Germany, etc.
The cryogenic tank consists of two tanks, the Outer & Inner Tank. The inner tank is made of stainless steel 304L (X5 CrNi 18-10) & design code EN13458, While the outer one is made of CARBON STEEL & design code EN13458.
The gap between tanks is filled with Perlite aggregation and superinsulation by vacuum technology.

Complete range of bulk cryogenic storage tanks and solutions delivering proven reliability, reduced maintenance, and lowest cost of ownership for the full spectrum of liquefied gases. Trailers, semi-trailers, swap bodies, liquid tube trailers, and railcars for safe and efficient distribution of non-flammable and flammable liquid gases.
