TPED/DOT/GB Aluminium Gas Cylinders—ISO 9000 Certified Supplier
Since 1998, DSW Industry has been a trusted manufacturer of high-quality aluminum cylinders and bottles, offering capacities ranging from 580 grams to 40 liters.
DSW is a leading global supplier of custom-engineered and standard fabrication services, tailored to meet diverse customer requirements—whether for bespoke solutions or routine applications.
Our aluminum alloy gas cylinders are widely used to contain calibration gases, mixed specialty gases, ultra-high-purity gases, oxygen, carbon dioxide, and even carbon monoxide.
Wide Range of Gases and Uses
DSW’s aluminum bottles and cylinders are used for various gases and applications:
- Ultra-high-purity gases for electronics
- Speciality and calibration gases
- Industrial gas supply
- Medical oxygen
- Food and beverage-grade CO₂
- SCUBA diving
- Fire and rescue operations
- Alternative fuel storage
- Aerospace missions
According to GB 11640-2011 standards, the primary material for our aluminium alloy cylinders is 6061 aluminium, known for its corrosion resistance, fatigue performance, and cold/hot working properties. Other approved aluminium alloys may be used, provided they pass tests for corrosion and crack resistance under constant load.
What are the sizes of aluminum cylinders?
| Model | Outer Diameter (mm) | Water Capacity (L) | Height (mm) | Weight (kg) | Working Pressure (MPa) | Design Wall Thickness (mm) |
|---|---|---|---|---|---|---|
| LW-60-0.5-20H | 60 | 0.5 | 285 | 0.6 | 20 | 3.1 |
| LW-75-0.7-15H | 75 | 0.7 | 295 | 0.9 | 15 | 4.0 |
| LW-82-0.7-15H | 82 | 0.7 | 235 | 0.9 | 15 | 4.2 |
| LW-89-1.0-15H | 89 | 1.0 | 269 | 1.2 | 15 | 4.5 |
| LW-89-1.4-15H | 89 | 1.4 | 345 | 1.4 | 15 | 4.5 |
| LW-108-1.0-15H | 108 | 1.0 | 210 | 1.3 | 15 | 5.5 |
| LW-108-1.4-15H | 108 | 1.4 | 264 | 1.6 | 15 | 5.5 |
| LW-108-2.0-15H | 108 | 2.0 | 346 | 2.1 | 15 | 5.5 |
| LW-108-2.5-15H | 108 | 2.5 | 413 | 2.5 | 15 | 5.5 |
| LW-120-2.0-15H | 120 | 2.0 | 320 | 2.7 | 15 | 6.1 |
| LW-120-2.5-15H | 120 | 2.5 | 369 | 3.0 | 15 | 6.1 |
| LW-120-2.8-15H | 120 | 2.8 | 398 | 3.2 | 15 | 6.1 |
| LW-120-3.2-15H | 120 | 3.2 | 437 | 3.5 | 15 | 6.1 |
| LW-140-4.0-15H | 140 | 4.0 | 420 | 4.2 | 15 | 7.1 |
| LW-140-5.0-15H | 140 | 5.0 | 500 | 4.9 | 15 | 7.1 |
| LW-140-6.0-15H | 140 | 6.0 | 580 | 5.6 | 15 | 7.1 |
| LW-140-8.0-15H | 140 | 8.0 | 741 | 7.2 | 15 | 7.1 |
| LW-140-5.0-20H | 140 | 5.0 | 525 | 6.3 | 20 | 9.3 |
| LW-140-6.0-20H | 140 | 6.0 | 652 | 7.98 | 20 | 9.3 |
Use cases for pressure Aluminum Cylinders.
Applications for aluminum gas cylinders range from industrial and commercial to personal and recreational.
– Industrial and manufacturing applications, where they store and transport gases for various processes and applications.
– In medical applications, hospitals and other healthcare facilities use them to store and transport medical gases.
– Aerospace applications, where they store and transport gases for use in aircraft and other aerospace applications.
– Personal and recreational use, such as camping, hiking, and other outdoor activities.
Durability and longevity of Aluminum Gas Cylinders
One key advantage of using Aluminium bottles is their durability and longevity. Unlike traditional steel cylinders, Aluminium tanks are resistant to corrosion and rust, making them ideal for various industrial and commercial applications. Additionally, they are less likely to deform or crack under pressure, which means they can be used for extended periods without deteriorating or becoming damaged.
Good corrosion resistance
Corrosion resistance is one of the primary uses for non-ferrous metal gas cylinders. Since different aluminium alloys possess unique chemical properties, the range and degree of corrosion resistance can vary.
Good heat transfer
Aluminum alloy boasts thermal conductivity several times that of steel, making it one of the highest thermally conducting materials, second only to copper.
High specific strength
Aluminum stands out among structural materials as having a lower density and a greater specific strength (ratio of tensile strength to density) than steel.
This trait makes it more suitable for mobile gas cylinders with lighter equipment weight, decreasing energy usage while saving costs during transportation.
Type 3 Gas Cylinders – Fully-wrapped carbon composite
Type 3 gas cylinders feature a thin and lightweight aluminum liner fully overwrapped with carbon composite. They offer weight savings over Type 2 cylinders (up to 30%). They can also be filled to higher pressures (up to 300 bar), offering increased capacity for the same size cylinder. Type 3 lightweight gas cylinders are ideal for applications where portability and power are essential, such as home oxygen therapy and medical oxygen cylinders in ambulances.
Suitable applications include:
Ambulatory oxygen
Portable field testing
Drone/UAVs
Fuel cell applications
Aerospace and military
Calibration
Applications of Aluminium Cylinders
Aluminium alloy gas cylinders are highly versatile and suitable for a broad range of professional and personal uses:
- Industrial and Manufacturing: Used for storing and transporting gases essential for process control, automation, and machinery operations.
- Medical: Commonly utilised in hospitals and healthcare facilities for storing medical-grade oxygen and other therapeutic gases.
- Aerospace: Deployed in aviation systems for the safe containment and transportation of critical gases under high pressure.
- Personal and Recreational: Ideal for outdoor applications including camping, hiking, and portable gas storage for mobile equipment.
